Google Campaign Manager 360 (CM360) Connector from Windsor.ai

How to export CM360 data?

Do you plan to connect and visualize your Google Campaign Manager 360 in data visualisation, data storage, data warehouse or BI tool?

Follow the Tutorial Below:



Step 1:

You need to select Campaign Manager 360 as a Data Source and grant access to Windsor.ai.



Step 2:

Select the fields on the right to later use in your data source. For example, you can include metrics such as Cost per Click, Cost per Action or Total Spend.



Step 3:

Select a destination to get Google Campaign Manager 360 (CM360) data into



How to link Google Campaign Manager (DCM) to Windsor.ai

This tutorial will help you to connect your Google Campaign Manager (DCM)

• Customer Journeys (Path to conversion reports)
• (Optional) Media costs, clicks, impressions



into Windsor.ai. Customer journeys will be modelled using Windsor.ai’s data driven attribution. There are a few steps involved to get it up and running.

First you need to set up a Windsor.ai account in case you don’t have one.

Once this is done, proceed with the steps below. Make sure to keep this window open as you’ll need it in a later step.



Granting access rights

In order for Windsor.ai to be able to retrieve Google Campaign Manager data through an API integration a user role needs to be created.

A general overview of user roles from Google can be found here



Prerequisites

• Admin Access to Google Campaign Manager (DCM)



1. Create User Role
   Log on to Google Campaign Manager and create a user role with the following rights

   User Role / Setting	Setting
   Identification
   User role name	Windsor.ai MTA User
   Trafficking
   Account management	read-only access
   Ads	read-only access
   Advertiser groups	read-only access
   Advertiser management	read-only access
   Billing Information	No access
   Campaigns	No access
   Content categories	full access
   Creatives	read-only access
   Floodlight	read-only access
   Path to conversion in Floodlight configuration	read-only access
   Placement costs	read-only access
   Placement strategies	No access
   Placements	read-only access
   Remarketing lists	read-only access
   Sites	read-only access
   Subaccounts	read-only access
   Tags	Yes
   User profiles	No
   User roles	No
   Reporting
   DDM reporting UI access	Yes
   Delete all generated files	No
   Delete all saved reports	No
   Edit Verification profiles	No
   Enable Verification	Yes
   Insert offline conversions	No
   Modify all saved reports	No
   Update offline conversions	No
   View all generated files	No
   View all saved reports	No
   View audience report	Yes
   View click-through conversions	Yes
   View cost	Yes
   View cross-device conversions	Yes
   View cross-dimension reach report	Yes
   View custom Floodlight variables data	Yes
   View DoubleClick Search data	Yes
   View Floodlight impressions and unattributed conversions	Yes
   View path to conversion reports	Yes
   View revenue data	Yes
   View time lag to conversion report	Yes
   View view-through conversions	Yes
   Planning
   All	No
   Orders: can approve	No
   Terms and conditions: full access	No



2. Planning
3. Create new user





Create a new user with the email address [email protected] and assign the role Windsor.ai MTA User to this user



Setting up path to conversion report

Go to report builder in Google Campaign Manager and create a new Path To Conversion report



In here you select the same settings as in the screenshot below and click SAVE AND RUN





Setting up media report

Go to report builder in Google Campaign Manager and create a new Standard report

In here you select the same settings as in the screenshot below and click SAVE AND RUN



Adding the reports to Windsor.ai

Now, add the reports you have set up to your account which you have created in Step 1.

1. Get the Report ID’s

2. Get the Account ID
3. Add the Account ID and Report IDs




Congratulations. Now Google Campaign Manager is connected.
